Communication protocol:
Rs485, CAN, LAN, Dry contact
* 2U standard 19inch case * Efficient, stable and reliable * size:W440*H88*D500mm
Accessories

 12S-24S BMU(Slave)
12S-24S BMU has 8pcs of tempreture sensors, Fan voltage 48V(17S-24S 12V), voltage detection range 0-5V,12V power
 supply,consumption less 20mA, CAN2.0 B communication
 Wire harness-Signal acquisition wire
18 Pin+20Pin wire, standard length is 600mm,900mm,1200mmtempreture sensor wire: standard length is 600mm,900mm,1200mm
 Fan wire: 600mm
 Wire harness-communication wire
Communication wire is connecting from master BMS to each BMU with cascade connection, the last port is for terminal resistance
Specification
 	 			Product Name
 			BMS

 			Model no.
 			RBMS07S2-3-50A288V

 			protecting method
 			MCCB+Contactor

 			Rated Current range
 			-50A~50A

 			Voltage Range
 			0V-288V

 			Current Sampling Accuracy
 			1.0%FSR

 			Communication interface with PCS
 			RS485/CAN

 			Communication interface with BMU
 			CAN

 			Communication interface with SBMS
 			RS485/CAN

 			Communication with monitoring software/EMS
 			Ethernet

 			Support IAP upgrade
 			Yes

 			Support HMI display and parameter
 			Yes(Optional)

 			Insulation detection
 			No

 			High voltage power module
 			Support DC start (optional)

 			Dry contact output (normally open)
 			Up to 3

 			Maximum qty of BMUs
 			5

 			Power
 			24VDC(18~28V)

 			Power consumption
 			≤20W

 			Size(W*H*D)mm
 			2U (440*88*500)

 			Way out
 			Front

 			Mid-line
 			Not support

 			Tap center
 			Not support

 			Net weight
 			14kg



Packing&Shipping

Why use a BMS

GCE 90s 288V 50A Master Slave BMS With 15s BMU CAN RS485 LAN Protocol

High Voltage BMS

Energy Storage BMS

Battery Management System

Integrated BMS

Master Slave BMS

UPS BMS

ESS BMS

BMS Solution

Relay BMS

EV BMS

Stackable High Voltage BMS

Battery Energy Storage System

Battery Power

GCE 90s 288V 50A Master Slave BMS With 15s BMU CAN RS485 LAN Protocol

GCE 90s 288V 50A High Voltage Relay Solution Master Slave BMS with 15s BMU for LFP NMC LTO BESS UPS EV PCBA Contactor

12S-24S BMU(Slave)

Wire harness-Signal acquisition wire

Wire harness-communication wire

Why use a BMS
